Jlon
HS CODE
E-GLASS
ROLL
1.0 meter
1.0mm
6*3.8
Availability: | |
---|---|
Fiberglass texturized cloth is woven by glass continuous texturized yarns in accordance with different requirements of density, thickness, structure, weave type and application, etc.
Because of stuffy yarns, the fabrics possess low density, low shrink, high strength, high temperature resistance, non-deformation, high coverage and insulation, and it’s widely used in the fields of filtration, air purification,industrial insulation, fire protection, composite coating, etc. More excellent performance will be obtained after being braided with copper wire, nickel wire or stainless steel wire.
The texturising process is key as it gives high temperature fabrics excellent thermal insulation capabilities, making them an excellent choice for applications that require thermal insulation or protection against heat and fire.
Due to the fluffy yarn and good air permeability, it can improve the filtration efficiency and reduce the filtration resistance, and the dust removal efficiency is higher, which can reach more than 99.5%.
Welding blankets
Expansion joints
Curtains
Removable insulation pads
Lagging
Safety gloves and high temperature personal protective equipment
For low temperature -70 ℃, high temperature between 1000 ℃, and can be resistant to transient high temperature.
Resistant to ozone, oxygen, light and climate aging.
High strength, high modulus, low shrinkage, no deformation.
Non-combustibility. Good heat insulation and heat preservation performance.
Over the working temperature, still has a certain residual strength.
Corrosion resistance.
Type | Weave | Warp | Weft | Width (cm) | Density (/cm) | Weight (g/m2) | Thickness (mm) |
---|---|---|---|---|---|---|---|
84215 | Plain | ET6-204 T 215 | ET6-204 T 215 | 100-220 | 8×6 | 280 | 0.38 |
2025 | Plain | ET6-408 T 430 | ET6-408 T 430 | 100-220 | 8×6 | 600 | 0.75 |
2626 | Twill | ET9-544 T 580 | ET9-544 T 580 | 100-220 | 10×6 | 950 | 1.00 |
M24 | Plain | ET9-816 T 860 | ET9-816 T 860 | 100-220 | 6×3.8 | 816 | 1.00 |
M30 | Plain | ET9-816 T 860 | ET9-1224 T 1250 | 100-220 | 6×4 | 1020 | 1.40 |
M35 | Plain | ET9-816 T 860 | ET9-1768 T 1800 | 100-220 | 6×3.8 | 1190 | 1.50 |
M52 | Plain Panama | ET9-816 T 860 | ET9-952 T 1290 | 100-220 | 6×2/2.5×2 | 1780 | 3.00 |
M35(G) | Plain Panama | ET9-612 T625(G) | ET9-612 T625(G) | 100-220 | 6×2/3.4×2 | 1200 | 1.50 |
EWTF750 | Satin Double Weft | ECT-68 1/2 | ET6-272 T 280 | 100-220 | 18×16 | 750 | 0.75 |
Note:Other special models depend on our customer's requirements.
Roll packaging: PE plastic film
This product should be deposited in the warehouse, avoiding sunshine and rain.
Prohibit contact with acid, alkali, oil and organic solvents.
Keep it clean and dry, 1m away from the discovery device.
Room temperature is between -15℃~40℃ It is recommended to be kept in intact package when not used to avoid damp.
Changzhou JLON Composite Co., Ltd.
A company who believes a satisfied customer is the best business accomplishment.
Changzhou JLON Composite Co. provides a wide range of reinforcements tailored to many applications such as construction, marine, pultruded profiles, transportation, wind energy, sports, etc. We’re one stop source for FRP raw materials.
In recent years we’ve entered new business axial fan and PVB/SGP film. Now there’re mainly two business sectors in our company:
A. Composite reinforcement materials and building materials:
Fiberglass products such as roving, chopped strand mat, woven roving, stitch mat, multiaxials, infusion mat, nonwovens for roofing, flooring, ceiling and walls of buildings
High performance fiber such as carbon fiber, aramid fiber, basalt fiber, high silica fiberglass, quartz
Core materials such as PVC/PET foam, PP honeycomb
Chemicals such as UP resin, vinyl ester resin, epoxy resin, SMC/BMC, MDI
Auxiliary materials such as infusion consumables, FRP tools
B. Axial fan:
We provide PAG and aluminum axial fan for HVAC, engineering equipment...We have different blades, hubs to satisfy customers’ specific needs.
A: Yes, We usually discuss with customers and help them find solutions.
A: Usually a sample will be prepared within one week after specification agreed.
A: Usually around 2-3 weeks after order confirmed. Exact delivery time depends on order quantity and Off-season/ busy season.
A: Offer TDS of each lot of production for confirmation before delivery.Once you have any quality problem, you can provide samples /pictures test data With our quality tracking system, we will give you feedback in short time. If the quality problem confirmed,we will send you replacement or make refund as you like.
A: Usually we do EXW, FOB, CIF and DDU
