JLON
Pallet and carton
1.81MPa
1.81MPa
1220X2440mm or 1000*2000mm or customized
12mm, 15mm, 17mm, 20mm, 25mm, 30mm
48kg/M3, 64kg/M3, 80kg/M3, 96kg/M3, 128kg/M3, 144kg/M3
Brown or Black
3926909090
Nomex Aramid Kevlar Honeycomb Datasheet.pdf
Aramid Kevlar Honeycomb is the standard for lightweight non-metallic composite construction. Commercial Grade Kevlar honeycomb made with aramid fiber paper (aramid or equivalent) coated with heat resistant phenolic resin offers excellent resiliency, low density, lower pricing and high strength to weight ratio.
Ultra lightweight, aramid honeycomb used in sandwich constructions. Unlike metals, nomex honeycomb provides galvanic corrosion resistance (also against corrosion of metal inserts) and allows the use of carbon skins. Other definite advantages are low thermal expansion and conductivity and high heat and fire resistance. Its superior mechanical properties and high dimensional stability under heat and moisture make it suitable for a large variety of high-end applications.
48kg/M3, 64kg/M3, 80kg/M3, 96kg/M3, 128kg/M3, 144kg/M3
very flexible, 3.2mm, 4.8mm, 6.4mm, 9.6mm or 1/8inch, 3/16 inch, 1/4inch, 3/8inch
• High strength to weight ratio
• Corrosion resistant
• Excellent dielectric properties
• Thermally insulating
• High toughness
• Excellent creep and fatigue performance
• Good thermal stability
• Over collapsed cell configuration suitable for forming simple curves
• Compatible with most adhesives used in sandwich composites
Cell size | Density | Compression Strength | Shear Strength | |||
mm | inch | Lb/ft3 | KG/m3 | Mpa | L direction-Mpa | W direction-Mpa |
3.2 | 1/8 | 3.0 | 48 | 1.9 | 1.16 | 0.62 |
3.2 | 1/8 | 4.0 | 64 | 3.1 | 1.48 | 0.82 |
3.2 | 1/8 | 5.0 | 80 | 4.7 | 1.95 | 1.05 |
3.2 | 1/8 | 6.0 | 96 | 6.6 | 2.45 | 1.42 |
3.2 | 1/8 | 8.0 | 128 | 11.3 | 2.95 | 1.73 |
3.2 | 1/8 | 9.0 | 144 | 13.2 | 3.05 | 1.9 |
4.8 | 3/16 | 2.0 | 32 | 0.9 | 0.58 | 0.36 |
4.8 | 3/16 | 3.0 | 48 | 2.6 | 0.98 | 0.56 |
4.8 | 3/16 | 4.0 | 64 | 3.4 | 1.7 | 0.92 |
4.8 | 3/16 | 5.0 | 80 | 6 | 1.95 | 1.1 |
4.8 | 3/16 | 6.0 | 96 | 7.3 | 2.26 | 1.32 |
4.8 | 3/16 | 7.6 | 123 | 9.3 | 3.4 | 1.86 |
6.4 | 1/4 | 1.5 | 24 | 0.54 | 0.34 | 0.18 |
6.4 | 1/4 | 2.0 | 32 | 0.8 | 0.54 | 0.3 |
6.4 | 1/4 | 3.0 | 48 | 2.05 | 1 | 0.56 |
6.4 | 1/4 | 4.0 | 64 | 3.4 | 1.54 | 0.79 |
9.6 | 3/8 | 1.5 | 24 | 0.52 | 0.32 | 0.16 |
9.6 | 3/8 | 2.0 | 32 | 0.68 | 0.56 | 0.29 |
9.6 | 3/8 | 3.0 | 48 | 9.6 | 1.15 | 0.66 |
Suitable for industrial or commercial use, such as Aircraft, Spacecraft, High speed vessel, Train, Radar etc.
Navy bulkhead joiner panels, helicopter rotor blades, fuel tanks, antennas, radar, flooring, boat hulls, auto racing bodies, train car panels, ship panels, ground transportation structures, ground antennas and special purpose panels
Aircraft
Railway
Wind Blade
Yatch
We can provide series products for Marine, for example, infusion materials(bagging film, release film, sealant tape...), PVC foam, PET foam, Nomex Aramid Kevlar Honeycomb, fiberglass products(chop strand mat, Quaxial fabric).
PP honeycomb, PET foam, PC honeycomb, Nomex Aramid Kevlar Honeycomb
PP honeycomb, PET foam, PC honeycomb,, Nomex Aramid Kevlar Honeycomb
Nomex Aramid Kevlar Honeycomb will be packaged in wooden case and then in pallet. We can package cargon with label for clients to recognize their products in different density and different thickness.
Nomex Aramid Kevlar Honeycomb is one of our common product, we have different kinds of stock to meet client's urgent small order quantity. Also, our production time for Nomex Aramid Kevlar Honeycomb is only 7-10days, so if you have bulk order of urgent delivery time, we can satisfy you.
Roll packaging: PE plastic film
Pallet packaging: Pallets should NOTbe stacked in more than 2 layers.
This product should be stored in a dry, ventilated and rainproof place, with temperatures from 5℃to 35℃ and humidity between 35% and 65%. It is recommended to be kept in intact package when not used to avoid damp.
Changzhou JLON Composite Co., Ltd.
A company who believes a satisfied customer is the best business accomplishment.
Changzhou JLON Composite Co. provides a wide range of reinforcements tailored to many applications such as construction, marine, pultruded profiles, transportation, wind energy, sports, etc. We’re one stop source for FRP raw materials.
In recent years we’ve entered new business axial fan and PVB/SGP film. Now there’re mainly two business sectors in our company:
A. Composite reinforcement materials and building materials:
Fiberglass products such as roving, chopped strand mat, woven roving, stitch mat, multiaxials, infusion mat, nonwovens for roofing, flooring, ceiling and walls of buildings
High performance fiber such as carbon fiber, aramid fiber, basalt fiber, high silica fiberglass, quartz
Core materials such as PVC/PET foam, PP honeycomb
Chemicals such as UP resin, vinyl ester resin, epoxy resin, SMC/BMC, MDI
Auxiliary materials such as infusion consumables, FRP tools
B. Axial fan:
We provide PAG and aluminum axial fan for HVAC, engineering equipment...We have different blades, hubs to satisfy customers’ specific needs.
A: Yes, We usually discuss with customers and help them find solutions.
A: Usually a sample will be prepared within one week after specification agreed.
A: Usually around 2-3 weeks after order confirmed. Exact delivery time depends on order quantity and Off-season/ busy season.
A: Offer TDS of each lot of production for confirmation before delivery.Once you have any quality problem, you can provide samples /pictures test data With our quality tracking system, we will give you feedback in short time. If the quality problem confirmed,we will send you replacement or make refund as you like.
A: Usually we do EXW, FOB, CIF and DDU
