750/980/1500GSM
JLON
E-GLASS
PALLET
1200mm/1270mm/2540mm
Plain weave/Twill weave
Black /Natural color
Twintex fabric, also called EPP60 fabric is a fabric made of roving which commingled E-glass and polypropylene filaments.
Consolidation is done by heating above melting temperature of PP matrix (180°C-230°C / 360°F-450°F) and applying a low pressure (1-30 bars), before cooling step under pressure.
According to the size of series, the product processings are:
•Vacuum molding
•Diaphragm
•Calendering
It is a unique and ready-to-use thermoplastics glass reinforcement designed for high mechanical properties, such as excellent stiffness/weight ratio and superior impact properties. EPP60 fabric also provides with efficient and environmental friendly process conditions, high freedom of design and is recyclable. EPP60 products are made of commingled High Performance Glass and thermoplastic filaments. Direct Roving is the base material for the whole EPP60 product line, and can be provided with Polypropylene Matrix (PP) and PET matrix.
TDS JL-EPP-6040-WR1500-T-B.pdf
Code | Color | Structure/ Pattern | Max width (cm) | Thickness (mm) |
PP- 60-P- 500-2800N/B | Natural Or Black | Plain/Twill | 280 | 0.35 |
PP- 60-P- 750-2800N/B | Natural Or Black | Plain/Twill | 280 | 0.50 |
PP- 60-T- 980-2800N/B | Natural Or Black | Twill | 280 | 0.70 |
PP- 60-T- 1500-2800N/B | Natural Or Black | Twill | 280 | 1.00 |
Conmon weight：750/980/1500gsm
Common width:1270mm
The twintex fabric itself contains thermoplastic pp filaments that do not need to be impregnated with other resins and can be used directly by heating at high temperatures.
Easy to use and store.
Epp60 fabric mainly made with honeycomb panels to make lightweight panels that can be used for camping caravans, trucks and other body parts. Mainly used for car insulation boards, partition boards.
A: Yes, We usually discuss with customers and help them find solutions.
A: Usually a sample will be prepared within one week after specification agreed.
A: Usually around 2-3 weeks after order confirmed. Exact delivery time depends on order quantity and Off-season/ busy season.
A: Offer TDS of each lot of production for confirmation before delivery.Once you have any quality problem, you can provide samples /pictures /test data. With our quality tracking system, we will give you feedback in short time. If the quality problem confirmed,we will send you replacement or make refund as you like.
A: Usually we do EXW, FOB, CIF, and DDU.
