Description of Thermoplastic UD TapesThermoplastic UD Tape is a high-performance unidirectional prepreg material made of continuous glass fibers (or carbon, aramid, basalt fibers) aligned in parallel and impregnated with molten thermoplastic resin through a melt impregnation process. |
|
Thermoplastic & Eco-friendly
100% recyclable, no VOC or formaldehyde emissions.
Melt Impregnation Technology
Ensures superior fiber wet-out, resulting in high strength and modulus.
Customizable Options
Resin Type: PE (main), PP, PC, PA, PET, etc.
Reinforcement Fiber: Fiberglass (main), Carbon fiber, Basalt fiber, Aramid fiber
Color: Natural, white, black, or customized
Thickness, fiber content, flame retardancy, and mechanical properties can be tailored upon request.
Name：Continuous glass fiber reinforced HDPE unidirectional prepreg tape
Product name: HDPE unidirectional prepreg tape
Thickness: 0.15mm-1mm
Width：25mm-750mm
Fiber type: continuous glass fiber (glass fiber content 45% - 80%)
Color: White and black, other colors can be customized
Surface: Fiber distribution is uniform, the surface is flat, no obvious waves, cracking, dry yarn, etc.
Thermoplastic UD Tapes are ideal for:
Reinforced Thermoplastic Pipes (RTP):
Used as the reinforcement layer in high-strength, corrosion-resistant pipelines for the oil and gas industry.
RTP pipes reinforced with continuous fiber thermoplastic tapes are lighter and stronger than traditional metal or pure plastic pipes.
Composite Structural Components:
Suitable for automotive, industrial, and construction reinforcement applications.
Filament Winding and Lamination Processes:
Easily processed by hot lamination, compression molding, and winding techniques.
