CSM225, CSM300, CSM450, CSM600, CSM900
JLON
E glass
Pallet and carton
Powder or Emulsion
1270mm or 1040mm or or customized
80-900gsm
White
70193100
Fiberglass
50,000,000kg
Chopped strand mat is produced by chopping continuous roving into length of 5cm and randomly dispersing the cut fibers. These fibers are held together by powder or emulsion binder. It is typically used for hand lay up process.The mats are compatible with unsaturated polyester, vinyl ester and PU resins. Width ranges from 50mm to 3200mm.
Chopped strand mat, good chemical resistance, high tensile strength, suitable for use in hand lay-up process to produce large-area parts; Good wet-through and fast wet-out in resins, rapid air lease; High mechanical strength; Superior acid corrosion resistance, Fiberglass chopped strand mat is compatible with unsaturated polyester, vinyl ester, epoxy and phenolic resins. It is designed for use in vacuum, hand lay-up, filament winding, compression molding and continuous laminating processes.
TDS chop strand mat-powder.pdf
TDS-chop strand mat-emulsion.pdf
1. Soft and good conformability
2. Excellent strength of composite products
3. Low resin consumption
4. Excellent acid-resistance of composite products
5. Fast and complete wet-out in resin easy roll out air
| Item | Weight(g/m2) | Binder Content(%) | Water Content(%) |
| EMC100 | 100 | 9-12 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
| EMC150 | 150 | 9-12 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
| EMC225 | 225 | 2-8 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
| EMC300 | 300 | 2-8 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
| EMC450 | 450 | 2-8 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
| EMC600 | 600 | 2-8 | <0.2 (powder bonded) <0.5 (emulsion bonded) |
Product:
We have professional production line, .
Before shipment, each product will be inspected in our lab to confirm its quality.
Our warehouse has extensive experience in storage and transport shipping.
And we can meet customer shipping requirement at any time.
End-use applications of chop strand mat include Nacelle, boats, bath equipment, automotive parts, chemical corrosion resistant pipes, tanks, cooling towers and building components.
Chop strand mat is one of our common product, we have different kinds of stock to meet client's urgent small order quantity.
Also, our production time for chop strand mat is only 3-5 days, so if you have bulk order of urgent delivery time, we can satisfy you.
Roll packaging: PE plastic film
Pallet packaging: Pallets should NOTbe stacked in more than 2 layers.
This product should be stored in a dry, ventilated and rainproof place, with temperatures from 5℃to 35℃ and humidity between 35% and 65%. It is recommended to be kept in intact package when not used to avoid damp.
Changzhou JLON Composite Co., Ltd.
A company who believes a satisfied customer is the best business accomplishment.
Changzhou JLON Composite Co. provides a wide range of reinforcements tailored to many applications such as construction, marine, pultruded profiles, transportation, wind energy, sports, etc. We’re one stop source for FRP raw materials.
In recent years we’ve entered new business axial fan and PVB/SGP film. Now there’re mainly two business sectors in our company:
A. Composite reinforcement materials and building materials:
Fiberglass products such as roving, chopped strand mat, woven roving, stitch mat, multiaxials, infusion mat, nonwovens for roofing, flooring, ceiling and walls of buildings
High performance fiber such as carbon fiber, aramid fiber, basalt fiber, high silica fiberglass, quartz
Core materials such as PVC/PET foam, PP honeycomb
Chemicals such as UP resin, vinyl ester resin, epoxy resin, SMC/BMC, MDI
Auxiliary materials such as infusion consumables, FRP tools
B. Axial fan:
We provide PAG and aluminum axial fan for HVAC, engineering equipment...We have different blades, hubs to satisfy customers’ specific needs.
A: Yes, We usually discuss with customers and help them find solutions.
A: Usually a sample will be prepared within one week after specification agreed.
A: Usually around 2-3 weeks after order confirmed. Exact delivery time depends on order quantity and Off-season/ busy season.
A: Offer TDS of each lot of production for confirmation before delivery.Once you have any quality problem, you can provide samples /pictures test data With our quality tracking system, we will give you feedback in short time. If the quality problem confirmed,we will send you replacement or make refund as you like.
A: Usually we do EXW, FOB, CIF and DDU
